Advantages

Benefits & advantages

  • blind with head rail in aluminium plastic construction
  • side leading bars prevent the penetration of light at the sides
  • selection from a wide collection of fabrics
Explore

Colour variants

clearance sale clearance sale
temporarily unavailable temporarily unavailable
Material design: 100% PES, 100% TREVIRA CS, GLASS FIBRE-PVC, PES/CV, PES/VISCOSE, PES/PA, PVC/PES

We also offer printing on fabrics with your logo, pattern, design, photo, etc.
Calculation and consultation with our sales representative is required for each print.
Printing on fabrics is possible from the following collections only:Tecno, Carina, Opera, Eko, Cloud, Carina BO color, Como, Mexico, New York, Starflex DIM, Sunblock, Sunmate, Veroglim, Verosafe, Creppe, Starlet DIM.

Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.
Methods

Handling

manually
metal chain (Ø 3,2 mm)
Guaranteed

Dimensions

minimum width
300 mm
maximum width
1400 mm
maximum height
1700 mm
maximum area
1,5 m2
Non-standard dimensions are not produced.
Guaranteed dimensions

Technical parameters

Thin tube Upper profile Bottom profile
for traditional version
Wiring
Guiding bar
area
Rope
Business name RRn 15/1 RR 07 RR 07/1 RR 08 RR 08/3 RR 14 silon 0,8 mm
IS 22
Dimensions  (mm) Ø 15 66 × 35 × 1 66 × 35 × 1 10 × 15 8 × 16 33,5 × 4 × 1
Material Fe Al PVC Al Fe Al
Cross-section Řez profilu Řez profilu Řez profilu Řez profilu Řez profilu
Colour   Standard:
RAL 8014
RAL 9010

Surcharge:
RAL 9006
RAL 8004
RAL 1002
RAL 1015
transparent

Construction versions

  • Construction with the flat aluminium leading bar

Assembly

  • on the window wing
