Zetta 70 external horizontal blinds

Detaily Zetta 70 external horizontal blinds Product gallery + + +
Zetta 70 external horizontal blinds together with Zetta 90 external blinds are technologically the most developed blinds in the area of exterior shading technology, and are recommended for the shading family houses and administrative buildings. Lamellas with a width of 7cm are in the form of the letter “Z”. When closed, the lamellas create a self-contained area which ensures perfect shading and the rubber impressed along the whole lamella increases the thermo-regulation of the blinds. Aluminium guiding bars ensure the stability of the blind during windy conditions and function as a supporting element for securing the property against break-ins. The variability of the assembly, the modern technical design and perfect shading enables this external horizontal blind to create a unique shading element for all types of objects.
I am interested in this product
Advantages

Benefits & advantages

  • high level of shading
  • thermoregulation and protective effect
  • decrease in the level of outside noise
  • lower profile from the extruded aluminium
  • electric control option
  • decrease in the noise from the blinds (impressed rubber)
  • guaranteed area of up to 18 m2.
Explore

Colour variants

Basic colours lamella

RAL 1015
RAL 1015
RAL 7016
RAL 7016
RAL 7016S
RAL 7016S
RAL 7022
RAL 7022
RAL 7035
RAL 7035
RAL 7038
RAL 7038
RAL 7048
RAL 7048
RAL 9006S
RAL 9006S
RAL 8014
RAL 8014
RAL 9005
RAL 9005
RAL 9006
RAL 9006
RAL 9007
RAL 9007
RAL 9010
RAL 9010
RAL 9016
RAL 9016
VSR 780
VSR 780
other colours

Colours at extra charge lamella

DB 702
DB 702
DB 703
DB 703
RAL 3004
RAL 3004
RAL 5002 - clearance sale clearance sale
RAL 5002
RAL 7021
RAL 7021
W 210
W 210

Colour performance Isotra System Decoral 1 at extra charge cover box, guiding rail, guiding rail holder, head + bottom rail

ISD 110
ISD 110
ISD 120
ISD 120
ISD 130
ISD 130
ISD 140
ISD 140
ISD 150
ISD 150
ISD 152
ISD 152
ISD 154
ISD 154
ISD 160
ISD 160
ISD 200
ISD 200
ISD 210
ISD 210
ISD 212
ISD 212
ISD 214
ISD 214
ISD 220
ISD 220
ISD 222
ISD 222
ISD 230
ISD 230
ISD 310
ISD 310
other colours

Colour performance Isotra System Decoral 2 at extra charge cover box, guiding rail, guiding rail holder, head + bottom rail

ISD 500
ISD 500
ISD 510
ISD 510
ISD 600
ISD 600
ISD 610
ISD 610
ISD 620
ISD 620
ISD 630
ISD 630
ISD 640
ISD 640
ISD 700
ISD 700
clearance sale clearance sale
Hereby stated colors are only indicative. If you want to see the color in real we recommend to visit one of our business partners where you can ask for physical swatch. We cannot accept claims for inappropriately chosen color according to electronic sampler.
Methods

Handling

manually
by handle
electrically
by remote control unit or switch
Guaranteed

Dimensions

minimum width
600 mm
maximum width
6000* mm
maximum height
4000 mm
maximum area
8 m2 (for handle control)
18 m2 (for motor control)
* Note: The wider the blind, the lower its wind resistance class – see Wind resistance, further down the page.

Non-standard dimensions are not produced.
Guaranteed dimensions

Technical parameters

Lamella Zetta 70 sketch
Lamella Zetta 70 sketch
Upper profile Lower profile Lamella Side guiding Ladder Textile strip
Leading bar Cord
Business name

 P 001/1 P 001/2 P 012/2
 P 038

 see Technical manual P 036
 P 029/2 P 531,
P531/1
Dimensions (mm) 56 × 58 58 × 60 67 × 13 0,42 × 83 see Technical manual Ø 3,2 60 × 9,5 6 × 0,28
Material Fe Al Al Al see Technical manual Fe / PVC PES PES
Cross-section Cross-section of profile Cross-section of profile Cross-section of profile Cross-section of profile
Colour Standard:
galvanized steel plate
natural (Al profil)
Other RAL colors sprayed,
DECORAL*		 Standard:
anodized aluminum
Other RAL colors sprayed,
DECORAL*		 According to the actual sampler from
ISOTRA a.s.		 Basic design – anodized
Varnished in RAL colors,
DECORAL*		 grey
black		 grey
black		 grey
black

*for max. width 4000 mm

Assembly options

Basic types of assembly

Assembly into created pocket (ceiling/wall)
Assembly into created pocket (ceiling/wall)
Assembly into reveal on the window frame (ceiling/wall)
Assembly into reveal on the window frame (ceiling/wall)
Assembly on expandig window profile (ceiling/wall))
Assembly on expandig window profile (ceiling/wall))

These three types of assembly can be in two versions: cover box visible cover box incorporated into heat-insulation system or peripheral shell.

Specific assembly

  • Self-bearing variant (fixation of the blind on guiding bars)
  • Façade variant (round cassette; assembly on the façade)
  • Assembly into Heluz lintel (built-in guiding bars)
  • Assembly into Porotherm lintel (recommended for separate constructions)
  • The self-supporting blind with packet of slats outside the head rail

It is necessary to consider assembly into a lintel in the plans for a family house.

Wind resistance

Wind resistance tests performed by Centrem stavebního inženýrství, a.s. in Zlín according to ČSN EN 13659.

Guiding rope

Essential characteristics Performance
  Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 3 6 2 5 1 4 0 3 0 2 0 1 0 0
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. effective height wing Hmax = 2500 mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 2 5 1 4 0 3 0 2 0 1 0 0 0 0
Max. wind speed vmax (km/h) 28 19 11 5 1 0
Max. effective height wing Hmax = 4000 mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to chosen slat colour)*

Guiding rail

Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 4   7 3 6 2 5 1 4
Max. wind speed vmax (km/h)  61 49 38 28
Max. effective height wing  Hmax = 4000 mm
Width of construction hole L (mm) 4 500 < L <= 5 000  5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 0    3 0 2   0 1 0 0
Max. wind speed vmax (km/h) 19  11 5 1
Max. effective height wing Hmax = 4000 mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to chosen slat colour)*
